MINI II : 5 WATT
1 Channel, 1 Input : 12" Speaker
The only thing small about this powerhouse 5 watt amp is its size. You won’t believe your ears when you hear this baby cat roar. Ideal for low-volume studio recording, the Mini II is a Class A, point-to-point wired, tube powered brute.

Experience the sweet tone of a dual overdriven 12AX7 pre-amp section and a single EL-84 power tube in your bedroom without disturbing your neighbors. Also features Line Out, Volume, Interactive Bass, Treble and Master Controls. 4, 8, 16 Ohm Selector.

Dimensions: 15.375"L x 16.5"H x 8.125"D : Weight: 30 lbs.

ALLEY CAT : 7.5 WATT
2 Channel, 1 Input : 12" Speaker
The 2 channel Alley Cat with channel switching packages incredible amounts of tone and gain into this little powerhouse amplifier, giving you 7.5 plus watts of Single Ended Class A power. It has become the choice for studio recording, bedroom levels, and powerful enough for smaller venues all in this small portable easy to use combo.

Control knobs include Channel 1: Clean Volume. Channel 2: Gain, Interactive Bass, Treble and Master Control. Uses 2 EL-84’s, 2 12AX7’s, plus a line out feature and a 4,8, and 16 ohm selector switch.

Dimensions: 15.375"L x 16.5"H x 8.125"D : Weight: 32 lbs.

click image to view back of amp

LIl' 15

The Lil' 15 (1449.00) is tiny !!! 15 watts of channel switching, duel EL-84 power! Channel one is similar to the Bad cat clean sound you have become familiar with in amplifiers such as the Cub II and the Black Cat. Channel two is a whole new breed of cat! Simply put, channel two of the Lil' 15 will blow you away. You will not believe how ferocious this Cat is, regardless of it's tiny size!

We started with our 15 watt, hand wound power and output transformers and made the amp as small as we could around the transformers, with the transformers taking up the whole height of the cabinet. This point-to-point design is in a class by itself!

The Lil' 15 is a great live or studio amp covering all ranges of sounds and tones. Footswitch included!

Dimensions: 14"L x 8.5"H x 7"D : Head only

CUB II & CUB II Reverb 15 WATT
1 Channel, 2 Input : Extension Speaker Out
Speaker Impedence Selector

A Big Cat in a small box. The Cub 15 Watt is available with or without reverb. The Cub delivers a pristine clean to warm and dirty output capability. The compact Cub’s are easy to transport, built like tanks. It can only be appreciated by putting a Cub through its paces. For creative and pleasing tones, you’ll find the Cub to be your most loyal performance tool.

Control knobs include Volume, Selectable 5-way Rotary Tone Switch or interactive Bass and Treble, Cut, Reverb, Master volume. The Cub’s dual EL84 power section with the 12AX7 pre-amp section boasts an uncommon array of tonal shapes.

Dimensions: 24"L x 18.5"H x 10.75"D : Weight: 55 lbs.

CLASSIC CAT / Reverb : 20 WATT
1 Channel, 2 Input : Line Out
Speaker Impedance Selector

The Classic Cat is all about simplicity and yet delivers rich, clean complex tone with amazing dynamic response all within two knobs. The Tone Control obtains a spectrum which has a more uniform sound that will allow you to adjust the frequency response achieving a more natural result. Whether you are using humbuckers or single coils, by using the amp’s volume, you guitar’s volume control and your pick attack, you can get varying degrees of clean to smooth overdriven sounds.

The Classic Cat dual 6V6 power supply with a 12AY7 preamp section delivers an array of tonal shapes.

Dimensions: 24"L x 18.5"H x 10.75"D : Weight: 53 lbs.

HOT CAT 15 / 30 WATT Hi-Gain
2 Channel, Gain and Clean : Dual Speaker Outs
Speaker Impedence Selector

The Hottest of all Cats. The concept and function of the Hot Cat is new, unique, and unlike any model ever produced by Bad Cat. The 12AX7 based pre-amp affords some overdrive loading if desired via the clean input, as well as sweep control of the clearly emphasized overdrive high gain input.

Control knobs include: Clean Volume, Gain, Edge, Level, Bass, Treble, Brilliance, and Gain Master Volume.

The power section supports a continuous thick overdrive speaker power and a strong reserve of clean headroom. The 15 Watt using dual EL84’s, the 30 Watt dual EL34's. In contrast to other Class A models to date, as regards extraordinary sound possibilities, the Hot Cat runs appreciably ahead of the pack.

Dimensions: 1x12 Combo: 24"L x 18.5"H x 10.75"D : Weight: 53 lbs.
Dimensions: Head: 9.5"H x 21"W x 10.5"D : Weight: 47 lbs.

HOT CAT : 30R / 100R
2 Channel, Gain and Clean : Dual Speaker Outs
Speaker Impedence Selector

The all new HOT CAT 30R takes the proven Hot Cat formula to the next level. Starting with the Hot Cat 30 platform we incorporated new functionality, flexibility and tonality. New features include a 5-position rotary tone select on the clean channel, a Mid Cut/Boost switch, tube buffered effects loop with send and return levels and reverb. This amp is a veritable Class A tone encyclopedia with tones ranging from chimey jangle to full-on distortion.

Our Channel Switching is unique by far. It does not rob your signal from your amp. When using channel switching you are able to switch between channels and also able to mix the channels together giving you more tonal possibilities. Disconnect the switching pedal and you are now able to plug into the front end of the amp using either channel. Our goal was to create a one-stop shop for Class A tone in the Hot Cat 30R. The 30R is available as a 1x12, 2x12 or head. No other Class A Hi-Gain even comes close.
Dimensions 30R: 24.375"L x 11"H x 11.625"D : Weight: 57 lbs.
Dimensions 100R Head: 24"L x 20.5"H x 11.625"D : Weight: 61 lbs.

TREM CAT : 30 WATT
1 Channel, 2 Input : Variable Tone Controls, Tremolo, Reverb, Hi-Lo Power, Speaker Impedence Switch, Speaker Phase Switch
The all new Trem Cat model incorporates a stunning combination of both speed and depth controlled Tremolo and spring Reverb to deliver the widest range of sound possibilities available from Bad Cat.

The Trem Cat control panel offers two inputs and: Volume, Tone, (EQ) Select, Bass, Treble, Speed, Depth, Cut, Master and Master On/Off. Power On/Off and the Standby toggles on the rear. Powered by 4xEL84’s for excellent clean headroom and significant reserve; the rear panel also includes a Hi/Lo switch for 15W attenuation. The sophisticated Pre-amp section harnesses unlimited sound shaping capability using a Pentode EF86 with a series of 12AX7’s for the interactive Tone, Tremolo and Reverb modules. Entirely based on Class A point to point circuitry, the Trem Cat is a gem of engineering design rendering it your best possible tool for creating a very broad range of truly satisfying sounds.

Dimensions: 24"L x 20.5"H x 11.5"D : Weight: 70 lbs.

BLACK CAT / Reverb : 30 WATT
2 Channel, 4 Input : Hi-Lo Power, Speaker Phase Selector, Extension Speaker Out, Speaker Impedance Selector, Channel Switching Available
The Black Cat 30 Watt is available with or without spring reverb. Incorporating two entirely different pre-amp sections, practical user controls render the smooth Black Cat as the most suitable guitar amp for any performance venue.

Channel One 12AX7 “Triode” pre-amp is based on interactive Bass and Treble controls. Channel Two EF86 “Pentode” based pre-amp uses a 5 position tone knob for instant access to your favorite sounds, or switch to an interactive bass and treble circuit. The 2x12” cab employs 2 dissimilar rated, Bad Cat proprietary Celestion speakers to further enhance the already shimmering harmonics. The Black Cat is regarded by many knowledgeable players as the finest, most capable guitar amp available today.

Dimensions: 28.5"L x 20.5"H x 11.5"D : Weight: 83 lbs.

PANTHER / Reverb : 35 WATT
With 35 watts of tube rectified 6V6 class A/B power, the Panther brings a whole new vibe to Bad Cat. The Panther tackles both sides of the pond with two independent channels… Channel 1 features a 12AX7 preamp with plenty of tone shaping features including bass, treble, mid, volume, and Bad Cat’s proprietary midrange and 5-way mid boost switch which will help you cut through any situation! Channel 2 jumps into the land of British sweetness and clang with its EF86 driven preamp and features a 5-way rotary "Tone" switch and volume. In lieu of the 5-way "Tone" rotary switch, a separate bass and treble knob can be engaged for shaping your sound. Beyond the aforementioned, a global cut allows you to tailor your sound. Both channels also feature master volumes which can be 100% switched out of the circuit if desired, and if that is not enough both channels can be operated together and blended to taste! In short, vintage tones with a modern twist!

The Panther’s rear panel features a half power switch, multiple taps (4, 8, & 16ohm), a two position voicing switch, line-out and speaker outputs. Power with 4- 6V6's.
Dimensions: 28.5"L x 20.5"H x 11.5"D : Weight: 83 lbs.
2X12 Combo, Also comes in 1X12 Combo and Head versions

WILDCAT Reverb : 40 WATT
2 Channel, 4 Input : Hi-Lo Power, Speaker Phase Selector, Extension Speaker Out, Speaker Impedance Selector Channel Switching Available
The Wild Cat 40 Watt model is available only with reverb. 2x12”, 1x12” or a head is available. Incorporating 2 entirely different pre-amp sections and same user controls as found on the Black Cat, there are several tuning differences between the smoother, more compressed Black Cat 30 Watt and the more aggressive, tighter Wild Cat 40 Watt.

As similar to the pre-amp sections of the Black Cat, the Wild Cat uses an interactive 12AX7 layout on Channel One and the 5 position or bass and treble, EF86 based Channel Two with the same Cut control.The 2x12” cab employs 2 similar rated, Bad Cat proprietary Celestion speakers to support a wall of sound: a noticeably strong and tight sound field. For tremendous clean power reserve when you need it, you can rely on the Dual EL34 ferocious Wild Cat.

Dimensions: 28.5"L x 20.5"H x 11.5"D : Weight: 85 lbs.

THE LYNX
What screams rock-n-roll better than 50 watts of burning "Class A" EL 34 power? The Lynx is capable of delivering sounds across the tonal spectrum, all without compromising itself within any setting. From articulate cleans, 70's Grind, 80's Hot Rodded to the heavy sounds of today.

Articulate cleans are available in Channel 1 and can be tailored to your ears delight via Bad Cat’s 5-way rotary tone switch and a single volume. If you want more growl than purr, crank the volume and dig in. Channel 2 provides the ultimate in tone shaping via treble, bass, midrange, Bad Cat's revolutionary 5-way rotary mid sweep, edge, and a master volume.

This Cat and can be heavily influenced by the array of tone shaping options on the rear panel, including our two position voicing switch and a half power option. 4, 8, and 16 ohm taps are also available to suit any cabinet option. A 1/4 line out , a half power switch is also provided as well! Powered by 2 - EL34's. Head only.

Dimensions: 24.5"L x 11.5"H x 11.625"D : Weight: 56lbs. Head only






Johnny Garcia of Garth Brooks with the new BC-50 head ($1599.00) and The "Leash" power attenuator ($349.00)
